DS-PD1-BG9
Wired Break-Glass Detector
- Dual color LED indicator
- High/Low sensitivity optional
- Anti-electromagnetic interference
- Anti-RF interference
Description
Wired Break-Glass Detector | ||
---|---|---|
Operation voltage: | DC 9-16V | |
Quiescent current: | ≤15mA(12 VDC) | |
Alarm current: | ≤25mA | |
Detection range: | High sensitivity:9m, Low sensitivity:5m | |
Test time: | ≤60s | |
Operating temperature: | -10℃ ~ +80℃ | |
Relay output: | NC, contact rating 28 VDC,80mA | |
Tamper switch: | NC, contact rating 28 VDC,100mA | |
Dimension(L x W x H) (mm): | 92 × 67 × 26.4 | |
Weight (g): | 100 |
