LED
Pixel Configuration: Surface mounted trinity LED
Encapsulation Brand: NationStar gold wire
Driver IC: MBI5153
Housing Included: Yes
Power Supply Brand: Megmeet
Control System: Hikvision-developed
Pixel Pitch: 1.27 mm
Dimensions (W×H×D): 609.92 × 343.08 × 75 mm (24.0 × 13.5 × 2.95 inch)
Packing Dimensions (W×H×D): 796 × 484 × 192 mm (31.33 × 19.05 × 7.56 inch)
Resolution: 480 × 270
Pixel Density: 619,350 pitch/ m²
Area: 0.209 m²
Aspect Ratio: 16:9
Material: Sealed die casting aluminum
Maintenance Method: Magnet front maintenance for lamp boards, and rear maintenance for power supply and receiving card
Max. Brightness: 500 nits
Brightness Control: Manual/Automatic/Remote controller
Color Temperature: 3000 to 6000 adjustable
Viewing Angle: Horizontal 160°, vertical 160°
Optimal Viewing Distance: 4 m
Center Distance Deviation of LED Brightness Uniformity: < 3%
Brightness Uniformity: ≥ 97%
Color Uniformity: ≤ ± 0.003Cx, Cy
Contrast: ≥ 3000:1
Driving Mode: Constant current driving
Frame frequency: 60 Hz
Refresh Rate: 3840 Hz
Power Supply: 100 to 240 VAC
Max. Consumption: ≤ 850 W/m²
Average Consumption: < 280 W/m²
Operating Temperature: –10°C to 40°C (14°F to 104°F)
Storage Temperature: –20°C to 60°C (–4°F to 140°F)
Operating Humidity: 10% to 80% (non-condensing)
Storage Humidity: 10% to 85% (non-condensing)
Gross Weight: 9.8 kg (21.6 lb including packaging)
Wet Weight: 9.3 kg (20.5 lb)
