Camera
Image Sensor: 1/1.8″ Progressive Scan CMOS
Signal System: PAL/NTSC
Min. Illumination: 0.002 Lux @ (F1.2, AGC ON), 0 Lux with IR
Shutter time: 1 s to 1/100,000 s
Slow shutter: Support
Lens: 2.8-12mm F1.4, angle of view: 92°~32°
Lens Mount: φ14
Auto Iris: DC drive
Adjustment Range: Pan: 0°~355°, tilt: 0°~75°, rotation: 0°~355°
Day& Night: IR cut filter with auto switch
Wide Dynamic Range: 120 dB
Digital noise reduction: 3D DNR
Compression Standard
Video Compression: H.264/MJPEG/MPEG4
H.264 code profile: Base Line Profile/ Main Profile/ High Profile
Video bit rate: 32Kbps~16Mbps
Audio Compression: -S: G.711/G.722.1/G.726/MP2L2
Audio bit rate: 64Kbps(G.711) / 16Kbps(G.722.1) / 16Kbps(G.726) / 32-128Kbps(MP2L2)
Dual Stream: Yes
Max. Image Resolution: 1920 x 1080
Frame Rate: 50Hz: 50fps (1920 × 1080,1280 × 960,1280 × 720)
60Hz: 60fps (1920 × 1080,1280 × 960,1280 ×720)
Image Settings: Rotate mode, Saturation, Brightness, Contrast adjustable by client software or web browser
BLC: Yes, zone configurable
HLC: Support
Smart Defog: Support
EIS: Support
3D DNR: Support
ROI: Support
Picture Overlay: Support 24-bit BMP image overlay, zone optional
Day/Night Switch: Auto, Schedule, Alarm trigger
Network
Network Storage: Built-in Micro SD/SDHC/SDXC slot, up to 128G, NAS(NFS, SMB/CIFS)
Alarm Trigger: Motion detection, tampering alarm, network disconnect , IP address conflict, storage exception
Protocols: TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP
PPPoE,NTP,UPnP,SMTP,SNMP,IGMP,802.1X,QoS,IPv6,Bonjour
General Function: One-key recovery, Anti-Flicker, three streams, heartbeat, mirror, password protection, video
mask, Watermark, IP address filtering
System Compatibility: ONVIF (Profile S, Profile G), ISAPI
Interface
Audio: 1-ch audio in, Mic in/Line in;
1-ch audio out
Communication Interface: 1 RJ45 10M / 100M Ethernet interface
Alarm: 1 Input /1 output (up to DC24V 1A or AC110V 500mA)
Alarm Input: 1
Alarm Output: 1
On-board storage: Built-in Micro SD/SDHC/SDXC slot, up to 128 GB
Reset Button: Yes
Smart Feature-set
Behavior Analysis: Line crossing detection, Intrusion detection, Region entrance, Region exiting, Unattended baggage, Object removal
Line Crossing Detection: Cross a pre-defined virtual line
Intrusion Detection: Enter and loiter in a pre-defined virtual region
Region Entrance: Enter a pre-defined virtual region from the outside place
Region Exiting: Exit from a pre-defined virtual region
Unattended Baggage: Objects left over in the pre-defined region such as the baggage, purse, dangerous materials
Object Removal: Objects removed from the pre-defined region, such as the exhibits on display.
General
Operating Conditions: -30 °C – 60 °C (-22 °F – 140 °F)
Humidity 95% or less (non-condensing)
-H: -40 °C – 60 °C (-40 °F – 140 °F) with smart heater on
Power Supply: 24 VAC/12 VDC/PoE (802.3at)
Power Consumption: 16W MAX
Weather Proof: IP67
IR Range: Up to 30m
Dimensions: Φ165.4 × 126.2
Weight: 3360g
