Camera
Image Sensor: 1/1.8″ Progressive Scan CMOS
Signal System: PAL/NTSC
Min. Illumination: Color: 0.002 Lux @ (F1.2, AGC ON)
B/W: 0.0002 Lux @ (F1.2, AGC ON)
Shutter time: 1 s to 1/100,000 s
Slow shutter: Support
Lens: 16mm F1.8 HFOV: 25°
Lens Mount: M12
Day& Night: IR cut filter with auto switch
Wide Dynamic Range: 120 dB
Digital noise reduction: 3D DNR
Compression Standard
Video Compression: H.264/MJPEG/MPEG4
H.264 code profile: Base Line Profile/ Main Profile/ High Profile
Video bit rate: 32Kbps~16Mbps
Audio Compression: G.711/G.722.1/G.726/MP2L2
Audio bit rate: 64Kbps(G.711) / 16Kbps(G.722.1) / 16Kbps(G.726) / 32-128Kbps(MP2L2)
Dual Stream: Yes
Triple Streams: Yes
Max. Image Resolution: 1920 x 1080
Frame Rate: 50Hz: 50fps (1920 × 1080,1280 × 960,1280 × 720)
60Hz: 60fps (1920 × 1080,1280 × 960,1280 ×720)
Third Stream: Independent with Main Stream and Sub Stream ,up to:
50HZ: 25fps(1920 × 1080)
60HZ: 30fps (1920 × 1080)
Image Settings: Rotate mode, Saturation, Brightness, Contrast adjustable by client software or web browser
BLC: Yes, zone configurable
HLC: Support
Smart Defog: Support
EIS: Support
3D DNR: Support
ROI: Up to 4 fixed areas in each stream or dynamic tracking
Picture Overlay: Support 24-bit BMP image overlay, zone optional
Day/Night Switch: Auto, Schedule, Alarm trigger
Network
Network Storage: NAS (Support NFS,SMB/CIFS)
Alarm Trigger: Motion detection, tampering alarm, network disconnect , IP address conflict, storage exception
Protocols: TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP,
PPPoE,NTP,UPnP,SMTP,SNMP,IGMP,802.1X,QoS,IPv6,Bonjour
General Function: One-key recovery, Anti-Flicker, three streams, heartbeat, mirror, password protection, video
mask, Watermark, IP address filtering
System Compatibility: ONVIF (Profile S, Profile G), ISAPI
Interface
Audio: 1 x 3.5mm audio input (Mic in / Line in) / output external interface
Communication Interface: 1 RJ45 10M / 100M Ethernet interface
Alarm: 1 input/1 output(up to DC24V 1A or AC 110V 500mA)
Alarm Input: 1
Alarm Output: 1
Smart Feature-set
Behavior Analysis: Line crossing detection, Intrusion detection, Region entrance, Region exiting, Unattended baggage, Object removal
Line Crossing Detection: Cross a pre-defined virtual line
Intrusion Detection: Enter and loiter in a pre-defined virtual region
Region Entrance: Enter a pre-defined virtual region from the outside place
Region Exiting: Exit from a pre-defined virtual region
Unattended Baggage: Objects left over in the pre-defined region such as the baggage, purse, dangerous materials
Object Removal: Objects removed from the pre-defined region, such as the exhibits on display.
General
Operating Conditions: -30 °C ~ 60 °C (-22 °F ~ 140 °F)
Humidity 95% or less (non-condensing)
Power Supply: DC 12V
Power Consumption: -R: max. 17 W
Non-R: max. 13 W
Weather Proof: IP67
Dimensions: 373.03×203.15×180
Weight: 6200g(13.67lbs)
