| General |
| Channel Choice: |
|
4 Channels CH1~CH4 |
| Weight: |
|
Around 1100g ( Transmitter and Receiver ) |
| Dimensions (H×W×D): |
|
270mm×90mm×90mm |
| Material: |
|
PC front cover; ABS Back Cover |
| Other additional functions: |
|
Receiving light Indicate ;OK Indicate ;Testing Terminal |
| Strategy to dew/frost: |
|
Ultrasonic structure |
| Sight: |
|
Removable type |
| Optic axis adjust angle (Vertical): |
|
16°(±8°) |
| Optic axis adjust angle: |
|
180°(±90°) |
| Tamper Output: |
|
Contact Output 1b DC 30V 0.05A max |
| Operation Temperature Range: |
|
-25°C~+55°C |
| Supply Current: |
|
95mA |
| Recommend supply Voltage: |
|
DC 12V or 24V(non-polarity) |
| Supply Voltage: |
|
DC10.5~28V(non-polarity) |
| Alarm Output: |
|
FORM C(NO/NC changeable), Contact ratings DC 30V 0.5A max. |
| Response Time: |
|
30~960ms |
| Light Source: |
|
Digital pulse IR LED |
| Detecting Way: |
|
3 beams Intercepted simultaneously |
| Beams NO.: |
|
3 beams |
| Max reaching distance: |
|
1500m |
| Alarm Distance: |
|
150m |
