Camera
Image Sensor: 1/2.8″ Progressive Scan CMOS
Signal System: PAL/NTSC
Min. Illumination: Color: 0.005Lux @ (F1.2, AGC ON), 0.017Lux @ (F2.2, AGC ON), 0 Lux with IR on
Shutter time: 1/3 s to 1/100,000 s
Slow shutter: Support
Lens: 1.16 mm @ F2.2, horizontal field of view: 180°, vertical field of view: 180°
Lens Mount: M12
Day& Night: IR cut filter with auto switch
Wide Dynamic Range: 120 dB
Digital noise reduction: 3D DNR
Compression Standard
Video Compression: H.265+/H.265/H.264+/H.264/MJPEG
H.264 code profile: Main Profile/High Profile
Video bit rate: 32Kbps~16Mbps
Audio Compression: -S: G.711/G.722.1/G.726/MP2L2/PCM
Audio bit rate: 64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)
Dual Stream: Yes
Max. Image Resolution: 2048×1536
Frame Rate: 50Hz:25fps (2048 × 1536, 1600 × 1200, 1280 × 960)
60Hz:30fps (2048 × 1536, 1600 × 1200, 1280 × 960)
Sub Stream: 50Hz: 25fps (352× 288, 704 × 576)
60Hz: 30fps (352 × 240, 704 × 576)
Image Enhancement: BLC/3D DNR
Image Settings: Rotate mode, saturation, brightness, contrast, sharpness and white balance adjustable by client software or web browser
BLC: Support
ROI: Support 1 fixed region for each stream
Day/Night Switch: Auto/Schedule/Triggered by Alarm In (-S model supports)
Network
Network Storage: Micro SD/SDHC/SDXC card with ANR (up to 128G), NAS (Support NFS, SMB/CIFS)
Protocols: TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6
General Function: One-key reset, Anti-Flicker, heartbeat, mirror, password protection, privacy
mask, Watermark, IP address filtering
System Compatibility: ONVIF (Profile S, Profile G), ISAPI
Interface
Audio: With –S model: 1 input (line in), 1 output
Communication Interface: 1 RJ45 10M / 100M Ethernet interface
Alarm: 1 alarm input, 1 alarm output (DC24V, 1A or AC110V, 500mA, max.)
On-board storage: Built-in Micro SD/SDHC/SDXC slot, up to 128 GB
Audio
Environment Noise Filtering: Support
Audio I/O: support
Audio Sampling Rate: 8 kHz/16 kHz/32 kHz/44.1 kHZ/48 kHz
Smart Feature-set
Line Crossing Detection: Cross a pre-defined virtual line
Intrusion Detection: Enter and loiter in a pre-defined virtual region
General
Operating Conditions: -10 °C to +50 °C (-14 °F to +122 °F), Humidity 95% or less (non-condensing)
Power Supply: 12 VDC ± 25%, PoE (802.3af Class3)
Power Consumption: DC 12V ± 25%, 2A, 4.8W
PoE(802.3af 36-57V, class 3), 0.4 – 0.7 A, 6.4W
IR Range: Up to 8m
Dimensions: Φ 119.9 × 41.2 mm (Φ 4.72″ × 1.62″)
Weight: 600 g (1.32 lbs.)
