Camera
Image Sensor: 1/3″ Progressive Scan CMOS
Signal System: PAL/NTSC
Min. Illumination: 0.01lux @(F1.2,AGC ON) ,0 Lux with IR
0.014lux @(F1.4,AGC ON), 0 Lux with IR
Shutter time: 1/3 s to 1/100,000 s
Lens: 2.8 – 12 mm @ F1.4,Angle of view: 98°-30.2°
Lens Mount: φ14
Adjustment Range: Pan:0° – 355°, Tilt: 0° – 75°, Rotation: 0° – 355°
Day& Night: IR cut filter with auto switch
Wide Dynamic Range: Digital WDR
Digital noise reduction: 3D DNR
Compression Standard
Video Compression: H.264/MJPEG
Video bit rate: 32Kbps~8Mbps
Audio Compression: -S: G.711/G.722.1/G.726/MP2L2
Dual Stream: Yes
Max. Image Resolution: 1280×960
Frame Rate: 50 Hz: 25 fps (1280 × 960), 25 fps (1280 x 720), 25 fps (704 x 576),
25 fps (640 x 480)
60 Hz: 30 fps (1280 × 960), 30 fps (1280 x 720), 30 fps (704 x 576),
30 fps (640 x 480)
Image Settings: Saturation, brightness, contrast adjustable through client software or web browser
BLC: Yes, zone configurable
ROI: Support
Network
Network Storage: NAS (Support NFS,SMB/CIFS)
Alarm Trigger: Line Crossing, Intrusion Detection, Motion detection, Dynamic analysis, Tampering alarm, Network disconnect , IP address conflict, Storage exception
Protocols: TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP,NTP,UPnP,SMTP,IGMP,802.1X,QoS,IPv6,Bonjour
General Function: User Authentication, Watermark, IP address filtering, anonymous access, flickerless, heartbeat, video mask
System Compatibility: ONVIF (Profile S, Profile G), ISAPI
Interface
Communication Interface: 1 RJ45 10M / 100M Ethernet interface
On-board storage: Built-in Micro SD/SDHC/SDXC slot, up to 128 GB
Reset Button: Yes
General
Operating Conditions: -30 °C ~ 60 °C (-22 °F ~ 140 °F)
Humidity 95% or less (non-condensing)
Power Supply: 12 VDC ± 10%, PoE (802.3af)
Power Consumption: Max. 5W
Impact Protection: IEC60068-2-75Eh, 50J; EN50102, IK10
Weather Proof: IP67
IR Range: Up to 30m
Dimensions: Φ 140 × 99.9 mm (Φ 5.51” × 3.94”)
Weight: 1000g
NOTE：: * “-S” series support 1-ch audio I/O and 1-ch alarm I/O
